Outdoor Digital Advertising Displays

2500cd/m2

2500cd/m2

Weather Proof

Weather Proof

Vandal Proof

Vandal Proof

temperature control system

Smart Tempaerature Control System

steel enclosure

Steel Enclosure

Anti Glare Glass

Anti Glare Glass

Wide Viewing Angle

Wide Viewing Angle

24/7 Usage

24/7 Usage

Plug and Play

Plug and Play

Network product

Network Upgrade Available

pcap touch

Touch Upgrade Available

Free Wall Mount

Free Wall Mount

Lifetime Technical Support

Lifetime Technical Support

Three Year Warranty

3 Years Warranty

Sunlight Readable

Sunlight Readable

Brightness is key when using outdoor Digital Signage, our Outdoor Digital Advertising Displays use Ultra High Brightness panels (2,500cd/m²) more than 8 times brighter than a standard LCD panel to allow easy readability in direct sunlight (22 inch model is 2,000cd/m²).

Weatherproof

Weatherproof

Suitable for the harshest of outdoor conditions – designed with a robust, corrosion protected, outer casing to give protection from both the elements and the public. The outer casing has an IP65 rating which means it keeps out all airborne swarf, dust and other particles as well as being protected from any wet weather conditions; broadening the range of possible environments.

Vandal Proof

Vandal Proof

The outer casing of our Outdoor Digital Signage Advertising Displays is made from mild steel as well as having thermally toughened glass. Controls and openings are hidden and not accessible by passersby.

internal air conditioning temperature control

Smart Temperature Control System

Not only are the outdoor Digital Signage displays able to withstand hot and cold surroundings but they are able to manage the internal conditions to maximise the life of your product. Built in air-conditioning can now be tailored to allow the display to work at an optimal level in any climate.

Anti Glare Glass

Anti-Reflective Glass

The glass frontage is also anti-reflective to help defuse direct sunlight shining on the display, improving overall clarity.

Plug and Play

Plug and Play

The Outdoor Digital Advertising Displays come with a built in HD Android media player, allowing you to update them using a USB memory stick. Load your pictures and videos onto a USB memory stick then insert it into the display, which will copy the files into its internal flash memory. Once you remove the memory stick the screen will then start playing the pictures and videos in a continuous loop.

Network product

Optional Network Upgrade

For a small charge you can also upgrade your screen to be networked, allowing you to remotely update your outdoor Digital Signage screen via LAN, WiFi or 3G using our cloud based CMS.

Free Landscape/Portrait Wall Mount

Free Landscape/Portrait Wall Mount

The display can be mounted in either landscape or portrait orientation, depending on the application. We also include a free wall mounting bracket that allows you to install your display in either landscape or portrait orientation and lock it in place.

Internal locker

Third Party Media Player

Should you need to run the screen from another source, such as a small sized third party media player or PC, there is a small secure internal locker in which to place your device.

Touch Screen

Hardware Modification

Optional extras include a touch screen upgrade, a 3G module for wireless updates and a built in camera for user interactivity. Other hardware integration is available on request.

digital signage water proof ip rated

SPECIFICATION

22 Inch – OW22D

DISPLAY AREA

270×477

UNIT SIZE

397x737x120

BRIGHTNESS CD/M2

2000

COLOUR

1.06B

PIXEL PITCH

0.2537x 0.2537

VESA HOLES

350×250

NET WEIGHT

20.05kg

GROSS WEIGHT

23.5kg

POWER CONSUMPTION (W)

130

Panel

RESOLUTION

1080×1920

ASPECT RATIO

16:9

BRIGHTNESS (CD/M2)

2500*
Excludes 22″

VIEWING ANGLE

178°

CONTRAST RATIO

8000:1

AV Inputs

VIDEO

HDMI, VGA

Power

INPUT VOLTAGE

AC110~240V (50Hz~60Hz)

Environmental

ENCLOSURE PROTECTION

IP65

OPERATING TEMPERATURE

-20 °C to 50°C

OPERATING HUMIDITY

10% – 80%

STORAGE TEMPERATURE

-30 °C to 60°C

STORAGE HUMIDITY

5% – 90%

Computer

MEDIA FORMATS

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

MEDIA RESOLUTION

1920×1080/1080×1920

INTERNAL MEMORY

6GB

CPU

Duel-Core Cortex-A9 @1.6GHz

GPU

Mali-400 MP4 @400MHz

RAM

1GB DDR3

ROM

8GB NAND

USB

USB2.0 HOST (x2)

LAN

10/100M Ethernet (Network version screen only)

WI-FI

802.11b/g/n (Network version screen only)

OS

Android 4.2.2

GRAPHIC ENGINE

OpenGL ES 1.1/2.0, OpenVG 1.1

Accessories

INCLUDED

AC Power Cable, Remote Control, Wall Mount

OPTIONAL

Touch Screen Upgrade, Network Upgrade, Camera

32 Inch – OW32D

DISPLAY AREA

396×702

UNIT SIZE

516x1041x130

COLOUR

1.06B

PIXEL PITCH

0.36375×0.36375

VESA HOLES

400×300

NET WEIGHT

35kg

GROSS WEIGHT

49kg

POWER CONSUMPTION (W)

190

Panel

RESOLUTION

1080×1920

ASPECT RATIO

16:9

BRIGHTNESS (CD/M2)

2500*
Excludes 22″

VIEWING ANGLE

178°

CONTRAST RATIO

8000:1

AV Inputs

VIDEO

HDMI, VGA

Power

INPUT VOLTAGE

AC110~240V (50Hz~60Hz)

Environmental

ENCLOSURE PROTECTION

IP65

OPERATING TEMPERATURE

-20 °C to 50°C

OPERATING HUMIDITY

10% – 80%

STORAGE TEMPERATURE

-30 °C to 60°C

STORAGE HUMIDITY

5% – 90%

Computer

MEDIA FORMATS

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

MEDIA RESOLUTION

1920×1080/1080×1920

INTERNAL MEMORY

6GB

CPU

Duel-Core Cortex-A9 @1.6GHz

GPU

Mali-400 MP4 @400MHz

RAM

1GB DDR3

ROM

8GB NAND

USB

USB2.0 HOST (x2)

LAN

10/100M Ethernet (Network version screen only)

WI-FI

802.11b/g/n (Network version screen only)

OS

Android 4.2.2

GRAPHIC ENGINE

OpenGL ES 1.1/2.0, OpenVG 1.1

Accessories

INCLUDED

AC Power Cable, Remote Control, Wall Mount

OPTIONAL

Touch Screen Upgrade, Network Upgrade, Camera

43 Inch – OW43D

DISPLAY AREA

526×934

UNIT SIZE

670x1410x140

COLOUR

16.7M

PIXEL PITCH

0.1615×0.4845

VESA HOLES

400×400/400×800

NET WEIGHT

52kg

GROSS WEIGHT

78kg

POWER CONSUMPTION (W)

250

Panel

RESOLUTION

1080×1920

ASPECT RATIO

16:9

BRIGHTNESS (CD/M2)

2500*
Excludes 22″

VIEWING ANGLE

178°

CONTRAST RATIO

8000:1

AV Inputs

VIDEO

HDMI, VGA

Power

INPUT VOLTAGE

AC110~240V (50Hz~60Hz)

Environmental

ENCLOSURE PROTECTION

IP65

OPERATING TEMPERATURE

-20 °C to 50°C

OPERATING HUMIDITY

10% – 80%

STORAGE TEMPERATURE

-30 °C to 60°C

STORAGE HUMIDITY

5% – 90%

Computer

MEDIA FORMATS

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

MEDIA RESOLUTION

1920×1080/1080×1920

INTERNAL MEMORY

6GB

CPU

Duel-Core Cortex-A9 @1.6GHz

GPU

Mali-400 MP4 @400MHz

RAM

1GB DDR3

ROM

8GB NAND

USB

USB2.0 HOST (x2)

LAN

10/100M Ethernet (Network version screen only)

WI-FI

802.11b/g/n (Network version screen only)

OS

Android 4.2.2

GRAPHIC ENGINE

OpenGL ES 1.1/2.0, OpenVG 1.1

Accessories

INCLUDED

AC Power Cable, Remote Control, Wall Mount

OPTIONAL

Touch Screen Upgrade, Network Upgrade, Camera

49 Inch – OW49D

DISPLAY AREA

603×1073

UNIT SIZE

746x1500x140

COLOUR

1.06B

PIXEL PITCH

0.565 x 0.565

VESA HOLES

500×400/500×800

NET WEIGHT

74kg

GROSS WEIGHT

95kg

POWER CONSUMPTION (W)

300

Panel

RESOLUTION

1080×1920

ASPECT RATIO

16:9

BRIGHTNESS (CD/M2)

2500*
Excludes 22″

VIEWING ANGLE

178°

CONTRAST RATIO

8000:1

AV Inputs

VIDEO

HDMI, VGA

Power

INPUT VOLTAGE

AC110~240V (50Hz~60Hz)

Environmental

ENCLOSURE PROTECTION

IP65

OPERATING TEMPERATURE

-20 °C to 50°C

OPERATING HUMIDITY

10% – 80%

STORAGE TEMPERATURE

-30 °C to 60°C

STORAGE HUMIDITY

5% – 90%

Computer

MEDIA FORMATS

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

MEDIA RESOLUTION

1920×1080/1080×1920

INTERNAL MEMORY

6GB

CPU

Duel-Core Cortex-A9 @1.6GHz

GPU

Mali-400 MP4 @400MHz

RAM

1GB DDR3

ROM

8GB NAND

USB

USB2.0 HOST (x2)

LAN

10/100M Ethernet (Network version screen only)

WI-FI

802.11b/g/n (Network version screen only)

OS

Android 4.2.2

GRAPHIC ENGINE

OpenGL ES 1.1/2.0, OpenVG 1.1

Accessories

INCLUDED

AC Power Cable, Remote Control, Wall Mount

OPTIONAL

Touch Screen Upgrade, Network Upgrade, Camera

55 Inch – OW55D

DISPLAY AREA

684×1215

UNIT SIZE

817x1637x145

COLOUR

1.073G

PIXEL PITCH

0.21×0.63

VESA HOLES

600×400/600×800

NET WEIGHT

76.5kg

GROSS WEIGHT

94.9kg

POWER CONSUMPTION (W)

430

Panel

RESOLUTION

1080×1920

ASPECT RATIO

16:9

BRIGHTNESS (CD/M2)

2500*
Excludes 22″

VIEWING ANGLE

178°

CONTRAST RATIO

8000:1

AV Inputs

VIDEO

HDMI, VGA

Power

INPUT VOLTAGE

AC110~240V (50Hz~60Hz)

Environmental

ENCLOSURE PROTECTION

IP65

OPERATING TEMPERATURE

-20 °C to 50°C

OPERATING HUMIDITY

10% – 80%

STORAGE TEMPERATURE

-30 °C to 60°C

STORAGE HUMIDITY

5% – 90%

Computer

MEDIA FORMATS

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

MEDIA RESOLUTION

1920×1080/1080×1920

INTERNAL MEMORY

6GB

CPU

Duel-Core Cortex-A9 @1.6GHz

GPU

Mali-400 MP4 @400MHz

RAM

1GB DDR3

ROM

8GB NAND

USB

USB2.0 HOST (x2)

LAN

10/100M Ethernet (Network version screen only)

WI-FI

802.11b/g/n (Network version screen only)

OS

Android 4.2.2

GRAPHIC ENGINE

OpenGL ES 1.1/2.0, OpenVG 1.1

Accessories

INCLUDED

AC Power Cable, Remote Control, Wall Mount

OPTIONAL

Touch Screen Upgrade, Network Upgrade, Camera

65 Inch – OW65D

DISPLAY AREA

803.5×1428.5

UNIT SIZE

990x1910x140

COLOUR

1.06B

PIXEL PITCH

0.744 x 0.744

VESA HOLES

700×400/700×800

NET WEIGHT

95kg

GROSS WEIGHT

120kg

POWER CONSUMPTION (W)

550

Panel

RESOLUTION

1080×1920

ASPECT RATIO

16:9

BRIGHTNESS (CD/M2)

2500*
Excludes 22″

VIEWING ANGLE

178°

CONTRAST RATIO

8000:1

AV Inputs

VIDEO

HDMI, VGA

Power

INPUT VOLTAGE

AC110~240V (50Hz~60Hz)

Environmental

ENCLOSURE PROTECTION

IP65

OPERATING TEMPERATURE

-20 °C to 50°C

OPERATING HUMIDITY

10% – 80%

STORAGE TEMPERATURE

-30 °C to 60°C

STORAGE HUMIDITY

5% – 90%

Computer

MEDIA FORMATS

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

MEDIA RESOLUTION

1920×1080/1080×1920

INTERNAL MEMORY

6GB

CPU

Duel-Core Cortex-A9 @1.6GHz

GPU

Mali-400 MP4 @400MHz

RAM

1GB DDR3

ROM

8GB NAND

USB

USB2.0 HOST (x2)

LAN

10/100M Ethernet (Network version screen only)

WI-FI

802.11b/g/n (Network version screen only)

OS

Android 4.2.2

GRAPHIC ENGINE

OpenGL ES 1.1/2.0, OpenVG 1.1

Accessories

INCLUDED

AC Power Cable, Remote Control, Wall Mount

OPTIONAL

Touch Screen Upgrade, Network Upgrade, Camera
