Infared Touch

Dual OS

Multiple AV Inputs

Commercial Grade IPS panel

Internal Locker

Integrated WI-Fi

10 Touch Points

24/7 Usage

No External PC Required

Integrated Speakers

LED Backlight

Lifetime Technical Support

3 Years Warranty

Dual OS
Experience the most versatile commercial touch screen on the market. With both Android and Windows operating systems installed on the integrated PC it cannot be beaten on flexibility. Easily switch from Windows to Android; this screen has it all in one convenient package. A Windows license will need to be purchased separately.

Infrared Touch
Infrared Touch Screens use the most robust and durable touch technology available. Designed for commercial use, infrared touch technology works by embedding LED lights and sensors into the bezel of a monitor above the glass. These LED’s beam a signal across to the corresponding sensor on the other side forming an invisible grid. When the grid is broken by a finger, or other solid object, the sensors can detect the touch point. Infrared touch screens are by far the most cost effective solution on the market.

10 Touch Points
Having up to 10 touch points allows for a wider variety of applications than ever before. This kind of functionality allows you to manipulate images, zoom in an out as well as perform many other touch gestures; much like you would with a domestic tablet. It also allows for multiple users interacting with the screen at one time.

White Version Available
As well as the classic black version the Infrared Freestanding Multi Touch Screen Posters with Dual OS are now also available in with a stylish and modern white enclosure.

IPS Panel
Accurately displays an image’s quality and colour depth at an 178° ultra wide viewing angle. There is no fall-off in colour accuracy and no diversion in contrast ratio at wide angles. From bright sunlight to the most challenging lighting environments these displays are designed to reproduce and maintain the ultimate colour temperature for lifelike images. The panel is also optimised for mounting in either landscape or portrait orientation.

LED Backlight
The LED backlight used is not only eco-friendly but also ensures the display has enhanced brightness and contrast. This technology increases the lifespan and reduces the power consumption by around 30%. This form of light technology is mercury free; safeguarding this screen’s eco friendliness.

24/7 Usage
Built with commercial grade panel and components these displays are designed to run 24/7 in constant use; unlike domestic tablets. The panel also has a lifespan of over 70,000 hours of continuous use. They can also be used in landscape or portrait orientation.

Attach External Devices
Although the screens have an integrated PC with two operating systems, there is also a possibility to attach external devices if required. Simply connect your device to the screen, via VGA or HDMI (for the video signal) and USB (for the touch functionality). The screen will then serve as your computer monitor and the touch functionality controls the cursor, essentially acting as your mouse. The third party PC or media player can be hidden inside the screen’s lockable internal compartment.

Touch CMS
The Freestanding Touch Screen Posters can be used as touch monitors if you connect your own PC or you can run your own touch software from the integrated Dual OS PC board with Windows and Android. However you can use our ground breaking new Touch Screen Content Management System that puts you in control as you create, deploy and touch your very own content on screen. First, you create your custom layouts with our user friendly software that requires no knowledge of coding to use. Then deploy the content from your PC direct to your Touch Screens in a matter of seconds. Now all that is left to do is touch as you let your content do the talking about your brand, company, service or product.


[fusion_builder_container background_color=”” background_image=”” background_parallax=”up” enable_mobile=”no” parallax_speed=”0.3″ background_repeat=”no-repeat” background_position=”left top” video_url=”” video_aspect_ratio=”16:9″ video_webm=”” video_mp4=”” video_ogv=”” video_preview_image=”” overlay_color=”” overlay_opacity=”0.5″ video_mute=”yes” video_loop=”yes” fade=”no” border_size=”0px” border_color=”” border_style=”solid” padding_top=”0″ padding_bottom=”0″ padding_left=”0″ padding_right=”0″ hundred_percent=”yes” equal_height_columns=”no” hide_on_mobile=”no” menu_anchor=”” id=””][fusion_builder_row][fusion_builder_column type=”1_1″ last=”yes” spacing=”no” center_content=”yes” hide_on_mobile=”no” background_color=”#a1a1a1″ background_image=”” background_repeat=”no-repeat” background_position=”left top” hover_type=”none” link=”” border_position=”all” border_size=”0px” border_color=”” border_style=”solid” padding=”10px” margin_top=”0″ margin_bottom=”0″ animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ animation_offset=”” id=””][fusion_text]

SPECIFICATION

[/fusion_text][/fusion_builder_column][fusion_builder_column type=”1_1″ background_position=”left top” background_color=”” border_size=”” border_color=”” border_style=”solid” spacing=”yes” background_image=”” background_repeat=”no-repeat” padding=”” margin_top=”0px” margin_bottom=”0px” class=”” id=”” animation_type=”” animation_speed=”0.3″ animation_direction=”left” hide_on_mobile=”no” center_content=”no” min_height=”none”][fusion_tabs design=”classic” layout=”horizontal” justified=”yes” backgroundcolor=”” inactivecolor=”” bordercolor=”” id=””][fusion_tab title=”Full Specification – PPCNET-Live” icon=””]
Full Specification

50 Inch

55 Inch

50 Inch L50E3-T

Display Area

625.4×1106.4

Unit Size

766x1850x79.5

Net Weight (kg)

72

Gross Weight (kg)

82

Footprint

779×400

Power Consumption (w)

105
55 Inch L55E3-T

Display Area

686.4×1215.8

Unit Size

827x1947x79.5

Net Weight (kg)

93

Gross Weight (kg)

103

Footprint

840×400

Power Consumption (w)

125
Panel

Resolution

1080×1920

Aspect Ratio

16:9

Brightness (cd/m2)

450

Viewing Angle

178°

Contrast Ratio

5000:1

Colour

16.7M
Touch

Touch Technology

Infrared

Touch Points

10

Glass Hardness

7H minimum
AV Inputs/Audio

Video

HDMI, VGA

Audio

Audio Socket (3.5mm)

Speaker Type

2W, 5Ω (x2)
Power

Input Voltage

AC110~240V (50Hz~60Hz)
Environmental

Operating Temperature

0°C to 50°C

Storage Temperature

-30°C to 60°C

Operating Humidity

10% to 80%

Storage Humidity

5% to 95%
Computer

CPU

Intel® Atom™ (Quad-core) x5-Z8350 Processor (2M Cache, up to 1.92 GHz)

RAM

4GB (DDR3L-RS 1600MHz)

Instruction Set

64-bit

Graphic Engine

Intel® HD Graphics 400 (8th Gen, Supports DirectX11.2, OpenGL4.4 and OpenCL 2.0)

Hard Drive/Internal Memory (eMMC)

64GB

USB

2 x USB 2.0

LAN

10/100/1000 Ethernet

Wi-Fi

802.11b/g/n

OS

Android 5.1.1
Windows® 8 /8.1 64-bit, Windows® 10 64-bit,
Windows 10 Pro (licence purchased separately)

Other

No accessible buttons or controls
Accessories

Included

Remote Control, User Manual, Power Cable,
USB to USB Cable, Wi-Fi Aerial
[/fusion_tab][/fusion_tabs][/fusion_builder_column][/fusion_builder_row][/fusion_builder_container][fusion_builder_container background_color=”#ffffff” background_image=”” background_parallax=”none” enable_mobile=”no” parallax_speed=”0.3″ background_repeat=”no-repeat” background_position=”center center” video_url=”” video_aspect_ratio=”16:9″ video_webm=”” video_mp4=”” video_ogv=”” video_preview_image=”” overlay_color=”” overlay_opacity=”0.5″ video_mute=”yes” video_loop=”yes” fade=”no” border_size=”0px” border_color=”” border_style=”solid” padding_top=”0″ padding_bottom=”0″ padding_left=”0″ padding_right=”0″ hundred_percent=”yes” equal_height_columns=”no” hide_on_mobile=”no” menu_anchor=”” id=””][fusion_builder_row][fusion_builder_column type=”1_1″ background_position=”left top” background_color=”” border_size=”” border_color=”” border_style=”solid” spacing=”yes” background_image=”” background_repeat=”no-repeat” padding=”” margin_top=”0px” margin_bottom=”0px” class=”” id=”” animation_type=”” animation_speed=”0.3″ animation_direction=”left” hide_on_mobile=”no” center_content=”no” min_height=”none”][fusion_accordion divider_line=”no” id=””][fusion_toggle title=”GALLERY” open=”no”]
Gallery
[FinalTilesGallery id=’5′]
[/fusion_toggle][fusion_toggle title=”VIDEO” open=”no”]
Videos
[fvplayer id=”1″]
[/fusion_toggle][fusion_toggle title=”DOWNLOAD” open=”no”]
Downloads

Spec Sheet – Black Version

50″ Infrared Freestanding Multi Touch Screen Poster – Spec Sheet

55″ Infrared Freestanding Multi Touch Screen Poster – Spec Sheet

Spec Sheet – White Version

50″ White Infrared Freestanding Multi Touch Screen Poster – Spec Sheet

55″ White Infrared Freestanding Multi Touch Screen Poster – Spec Sheet

Technical Drawings

50″ Infrared Freestanding Multi Touch Screen Poster – Technical Drawing

55″ Infrared Freestanding Multi Touch Screen Posters – Technical Drawing

User Manual

Infrared Freestanding Multi Touch Screen Poster – User Manual

Hardware Setup Sheet

RS-232 Control

Touch CMS User Manual

Touch Screen Digital Signage User Manual

Photos

Infrared Freestanding Multi Touch Screen Posters – Application Images

Infrared Freestanding Multi Touch Screen Posters – White Background Images
[/fusion_toggle][/fusion_accordion][/fusion_builder_column][/fusion_builder_row][/fusion_builder_container]
